    One-Time Blown PBL Tube Packaging Mono PE Material Recyclable

    Ask Lasest Price
    Brand Name : Xuntang
    Model Number : One-time Blown Tube Laminate
    Certification : ISO
    Price : USD
    Payment Terms : T/T
    Supply Ability : 6M SQM per month
    Delivery Time : 25~30work days
    • Product Details
    • Company Profile

    One-Time Blown PBL Tube Packaging Mono PE Material Recyclable

    One-time Blown PBL Tube Laminates Mono-PE Material Recyclable

    Circular economy Mono-PE One-time-formed PBL Tube Laminates

    • Compared with the same extruded composite PBL tube laminate, the one-time blown tube has a significant improvement in water resistance and oxygen resistance
    • One-time blown tube laminate can replace ABL tube laminate of the same thickness
    • One-time Blown Tube Laminate has good penetration resistance and corrosion resistance,better performance in tube printing and tube making
    • Mono material >95% can be recycled and reused

    Test Data Comparison Table as below:


    Test ItemsUnitPBL-EVOH

    (A)

    PBL-EVOH

    (B)

    PBL-60%HD

    One-formed

    PBL-60%HD

    One-formed

    PBL-40%HD

    One-formed

    ABL-AL

    (C)

    1Average Thicknessμm400.0310.0350.0275.0250.0255.0
    2MDYield StrengthMPa15.115.621.721.518.421.2
    Secant ModulusMPa411459651681621801
    Tensile StrengthMPa21.021.022.525.929.224.8
    Breaking Elongation%710540260780770600
    3TDYield StrengthMPa16.416.921.721.118.321.9
    Secant ModulusMPa473510651669624823
    Tensile StrengthMPa19.117.022.526.226.221.9
    Breaking Elongation%660380510810730640
    4Puncture ResistanceN11.39.011.49.38.68.6
    5Glossiness(45º)40.252.440.641.541.341.2
    6OTR(23℃,0%RH)cm3/m2.day0.70.60.220.280.300.1
    7WVTR(37.8℃,90%RH)g/m2.day0.81.10.440.540.640.2

    Conclusions:

    1. The MD and TD yield strength of the once-formed tube is 25-30% greater than the extruded laminate PBL tube (A,B), making it more rigid.
    2. 60% HD one-formed tube and aluminum-plastic ABL tube(C) have the same yield strength, so the mechanical properties and hardness are equivalent under the same thickness.
    3. Compared with the extruded laminate PBL tube(A,B) of the same thickness, the one-formed tube has greatly improved water-blocking and oxygen-blocking performance.
